Schneider Electric HGL36000S15 Square D Circuit Breaker 150A 3P-New Surplus
Ready to Ship Next Business Day
The Square D HGL36000S15 is a 3 Pole non-automatic molded case circuit breaker with a current rating of 150 Amps and a voltage rating of 600V. It has an interrupting rating of 35kAIC@480V. The HGL36000S15 has a unit mounting type and includes NA - no overcurrent protection functions.
|
Brand |
Square D |
|
Series |
HGL |
|
Amperage |
150 |
|
Voltage |
600 |
|
Poles |
3 |
|
Phase |
3 |
|
Mounting Type |
Unit |
|
Approval |
CE, IEC, NMX, UL, CCC, CSA |
|
Interrupting Rating |
35kAIC@480V |
|
Frame Type |
HGL |
|
Connection Type |
Feed-Thru |
|
Protection |
Non-Automatic |
|
Functions |
NA - No Overcurrent Protection |
|
Terminal Connection |
Lug |
|
Length (in) |
4.36 |
|
Width (in) |
2.12 |
|
Height (in) |
6.4 |
|
Wire Gauge |
AWG 14, AWG 3/0 (Aluminium/Copper) |
|
Circuit Breaker Type |
Shunt Trip |
|
Actuator Type |
Toggle |
|
Max Wire Size |
3 AWG |
|
Min Wire Size |
14 AWG |
|
Mpn |
HGL36000S15 |
|
Upc |
785901433958 |
|
Gtin |
785901433958 |
