Crosby G-2160E Wide Body Sling Shackle - 125 Ton WLL - #1021509

PRODUCT DESCRIPTION

• Increase in shackle bow radius provides minimum 58% gain in sling bearing surface and eliminates need for a thimble
• Increases usable sling strength a minimum of 15% and greatly improves life of wire rope slings
• Can be used to connect synthetic web slings, synthetic round slings or wire rope slings
• All sizes Quenched & Tempered for maximum strength
• Forged alloy steel from 75 through 300 metric tons
• Proof tested as follows:
  • 75 metric tons and 200-300 metric tons: 2 x WLL
  • 125 metric tons: 1.6 x WLL
  • All ratings are in metric tons, embossed on side of bow
• G-2160E, (75t and larger), bows are furnished Dimetcoted, and pins are Dimetcoted, then painted red
• Shackles are RFID equipped
• Approved for use at -40° C (-40° F) to 204 degrees C (400° F)
• Bow and bolt are certified to meet Charpy impact testing of 42 Joules (31 ft-lb) min. avg. at -20° C (-4 degrees F)
• All 2160E shackles are individually proof tested and magnetic particle inspected; Crosby certification available at time of order
• Shackles requiring ABS, Lloyds and other certifications are available upon special request and must be specified at time of order
• Shackles have DNV Type Approval to Rules for Certification of Lifting Appliances, and are produced in accordance with DNV MSA requirements; databook is provided that includes required documents:
  • Serialization / Identification
  • Material Testing (physical / chemical / Charpy)
  • Proof Testing
• Look for the Red Pin®... the mark of genuine Crosby quality
• MPN:

  1021509
  Model

  G-2160E
  Size

  6.8"
  Type

  Wide Body
  Material

  Alloy Steel
  WLL (tons)

  125
  WLL (lbs)

  275,000
  Safety Factor

  5:1
  Overall Length

  23.00"
  Overall Width

  15.47"
  Throat Opening

  5.12"
  Pin Diameter

  3.15"
  Approx. Weight (lbs)

  190

This is a reconditioned product and is in full operational condition. Photo may not represent the actual product which may or may not contain some cosmetic blemishes that do not interfere with functionality. We offer a 1-year operational warranty on all reconditioned equipment. These units have been repainted and the manufacturer's logo may or may not be visible.  GES will attempt to comply with, but will not guarantee, shipping date and or delivery date. Buyer shall have fifteen (15) days from the date of delivery to accept product.
