Raychem JBS-100-ECP-A Power Connection Box and Digital Controller - New Surplus
Combination power connection box and digital controller designed for Raychem polymeric and MI heating cables in nonhazardous locations.
Features
- Programmable digital display with LED indicators
- RTD failure, high/low temperature alarm with remote output
- Pipe temperature maintenance up to 425°F (218°C)
- Double-pole mechanical relay switching
- Type 4X fiberglass-reinforced enclosure
- Cold-applied core sealer for simplified installation
Included
- JBS-100-ECP-A Controller Unit
- Digital Display and Programming Panel
- RTD Temperature Sensor (10 ft lead)
- Mounting Hardware (except pipe strap)
Specifications
| Voltage | 100–277 VAC, 50/60 Hz |
|---|---|
| Current Rating | 30 A max |
| Control Range | 32°F to 425°F (0°C to 218°C) |
| Accuracy | ±3°F (1.7°C) |
| Alarm Relay | Form C, 2 A at 277 VAC / 48 VDC |
| Sensor Type | 100-ohm Platinum RTD |
| Set Point Adjustability | Push Button Interface |
| Memory | Non-volatile |
Dimensions
| Height | 6.3 in |
|---|---|
| Width | 6.3 in |
| Depth | 3,5 in |
| Weight | 4.43 lbs |
Disclaimer
Buyer understands that the Goods described herein are new surplus by persons other than GES. GES is not obligated to do any repair work or modifications upon the Goods prior to sale or delivery. Any modifications performed by GES on the Goods prior to sale shall be performed as a result of the sole request of Buyer using designs and instructions provided by Buyer.
GES will attempt to comply with, but will not guarantee, shipping date and or delivery date. Buyer shall have fifteen (15) days from the date of delivery to accept product.
